Warehouse Electric Forklift Purshase
1. Low prices but high quality wheel loader and forklift—now that the competition is fierce, we must follow market principles and adopt a strategy of small profits but quick turnover from our wheel loader and forklift.
2. No matter how many years have passed, you can always get original parts of our wheel loader and forklift from us, as our products are designed for long-lasting use.
3. As the manufacturer, we handle our own production, which allows us to offer customized solutions even if you're purchasing just a single unit.
- Information
Model |
| CPD35 |
Power type |
| Acid Battery |
rated lifting capacity |
| 3500 kg |
load center distance |
| 500 mm |
length with fork | L1 | 4180mm |
length without fork | L2 | 2960 mm |
whole width | B | 1280 mm |
height no lifting frame | H1 | 2570 mm |
top frame height | H2 | 5056 |
Max. height working | H3 | 4005 mm |
distance from seat to top light | L3 | 972 mm |
wheel base | L4 | 1700 mm |
front overhang | Y | 475 mm |
back overhang | L5 | 490 mm |
front wheel tread | R | 1068 mm |
back wheel tread | P | 968 mm |
Min. floor clearance | F | 105 mm |
Max. lifting height | H | 4000 mm |
free lifting height | H4 | 145 mm |
fork changing | S | 250-1100 |
Min. turning radius | WA | 2380 mm |
Min right angle aisle width | RA | 4220 mm |
frame angle | α/β | 6/6 |
Max. lifting speed without goods |
| 450 mm/s |
Max lifting speed with full goods |
| 330 mm/s |
Max. speed without goods |
| 15km/h |
max. speed with goods |
| 11km/h |
whole weight |
| 4600 kg |
wheels qty |
| 2/2 |
tire model |
| solid |
front tire |
| 28*9-15 |
rear tire |
| 650-10 |
hand brake |
| hydraulic-pedal |
brake type |
| M-Hand |
battery Volt/capacity |
| 80V/200Ah |
Driving motor power |
| 22kw |
pump power |
| 15.5 kw |
1. Turn on the machine by swiping the card 2. Electric park brake |
|
