New Reach Truck Electric Forklift
1. Low prices but high quality wheel loader and forklift—now that the competition is fierce, we must follow market principles and adopt a strategy of small profits but quick turnover from our wheel loader and forklift.
2. No matter how many years have passed, you can always get original parts of our wheel loader and forklift from us, as our products are designed for long-lasting use.
3. As the manufacturer, we handle our own production, which allows us to offer customized solutions even if you're purchasing just a single unit.
- Leiya
- Qingzhou, China
- 10-20 days
- 60 sets/month
- Information
Model |
| CPD25 |
Power type |
| Battery |
rated lifting capacity |
| 2500 kg |
load center distance |
| 500 mm |
length with fork | L1 | 3527mm |
length without fork | L2 | 2457 mm |
whole width | B | 1180 mm |
height no lifting frame | H1 | 2015 mm |
top frame height | H2 | 2195 mm |
Max. height working | H3 | 4005 mm |
distance from seat to top light | L3 | 972 mm |
wheel base | L4 | 1550 mm |
front overhang | Y | 475 mm |
back overhang | L5 | 438 mm |
front wheel tread | R | 968 mm |
back wheel tread | P | 954 mm |
Min. floor clearance | F | 115 mm |
Max. lifting height | H | 3055 mm |
free lifting height | H4 | 145 mm |
fork changing | S | 250-1000 |
Min. turning radius | WA | 2200 mm |
Min right angle aisle width | RA | 3975 mm |
frame angle | α/β | 6/12 |
Max. lifting speed without goods |
| 450 mm/s |
Max lifting speed with full goods |
| 330 mm/s |
Max. speed without goods |
| 16.5km/h |
max. speed with goods |
| 15km/h |
whole weight |
| 3960 kg |
wheels qty |
| 2/2 |
tire model |
| solid |
front tire |
| 23*9-10 |
rear tire |
| 18*7-8 |
hand brake |
| hydraulic-pedal |
brake type |
| M-Hand |
battery Volt/capacity |
| 48V/500Ah |
Driving motor power |
| 11kw |
pump power |
| 12 kw |
notes |
| Batteries are optional |
